Aten Converter, VGA to HDMI with audio - VC180

Aten
ATVC180CONCONVR
R 1,377.73 Ex VAT

• Converts VGA signals to HDMI output

• Supports analogue stereo audio input

• Superior video quality – up to 1080p, WUXGA

• Screen Position Button – screen position settings can be stored for each output resolution

• Multiplatform support – Windows and Mac

• Supports dual power sources: VGA port or power adapter (in case the VGA port cannot provide sufficient power)

• Automatically detects video input signals

• LED indicator

• HDMI compatible

• Compact and lightweight

• No software required – eliminates incompatibility and installation issues

The VC180 is a VGA-to-HDMI Converter with Audio that lets you view VGA source data in an HDMI output display with stereo sound quality. It uses dual power sources – from the VGA port or a power adapter. The VC180 gets its power supply from the VGA port. However if your source device is not capable of supplying power, use the power adapter to connect the VC180 to a power source. The VC180 is compact, flexible and convenient to install – with no software required. Simply make the hardware connections and enjoy the experience.

Package Contents

1x VC180 VGA to HDMI Converter with Audio

1x Power Adapter

1x User Instructions



Video Input

Interfaces

1 x HDB-15 Female (Blue)

Impedance

75 Ω

Video Output

Interfaces

1 x HDMI Type A Female (Black)

Impedance

100 Ω

Video

Max. Pixel Clock

165 MHz

Max. Resolution

Up to 1080p

Audio

Input

1 x Mini Stereo Jack Female (Green)

Connectors

Power

1 x DC Jack

Power Consumption

DC5V:2.62W:12BTU

Environmental

Operating Temperature

0 - 50 ºC

Storage Temperature

-20 - 60 ºC

Humidity

0 - 80% RH, Non-Condensing

Physical Properties

Housing

Metal

Weight

0.16 kg ( 0.35 lb )

Dimensions (L x W x H)

7.90 x 7.81 x 2.44 cm
(3.11 x 3.07 x 0.96 in.)

Carton Lot

20 pcs

Note

For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.



VC180 Datasheet PDF
