Epson Business Projector, 5000 Ansi Lumens, 4KE resolution, 21:9 Aspect Ratio - EB810E

R 61,562.50 Ex VAT

• Super UST 4KE laser display

• EB-810E, Epson’s first 4KE super-ultra-short-throw laser display designed for businesses, hybrid working and immersive spaces

• The EB-810E can be placed just centimetres away from a wall to create bright 4KE images up to 160”.

• It projects content in stunning clarity and offers a low cost, energy efficient large display solution with a convenient and quick set up.

EB-810E's super-ultra-short-throw lens allows discreet positioning close to the wall, enabling presenters free access without casting shadows.

With 5,000 lumens CLO and 3LCD technology, the EB-810E is bright and vibrant up-to 160", which enables content visibility from all angles and distances. The experience is immersive and it's extremely simple to use.

Versatile wired and wireless connectivity options, including Miracast™ screen mirroring, ensure effortless, multi-device content sharing.

Weighing only 12.3kg, it is highly portable, and the Epson Setting Assistant App makes setup quick and simple. The ideal display solution suitable for different room sizes, combined with flexible installation options.

The EB-810E supports multiple aspect ratios and multi-projector edge-blending for a low cost, seamless, energy efficient ultra-wide display, perfect for video conferencing.

Paired with Epson's Ambient Light Rejection Screen, the EB-810E's image quality could be mistaken for a video wall or LED display, but it is surprisingly affordable and consumes a fraction of the energy.

Key Features

• Scalable 4KE display for any room 80-160" UST display for unrestricted viewing (no shadows/reflections)

• Bright and energy efficient laser 5,000 lumens CLO with 3LCD technology for brighter colours

• Effortless connectivity options Auto-on, wired/wireless display with USB 2A output for smart sticks

• Simple to use and built to last Virtually maintenance free with 5-year, 12,000hr warranty

• LED/Video wall alternative Surprisingly affordable with low energy consumption


• Projection System

3LCD Technology, RGB liquid crystal shutter

• LCD Panel

0, 62 inch with C2 Fine

• Colour Light Output

5.000 Lumen- 3.500 Lumen (economy) In accordance with IDMS15.4

• White Light Output

5.000 Lumen - 3.500 Lumen (economy) In accordance with ISO 21118:2020

• High Definition

4K enhancement

• Aspect Ratio


• Contrast Ratio

Over 2.500.000: 1

• Light source


• Laser Light source

20.000 hours Durability High, 30.000 hours Durability Eco

• Colour Video Processing

10 Bits

• 2D Vertical Refresh Rate

192 Hz - 240 Hz

• HDR support



• Throw Ratio

0, 16 - 0,40:1

• Zoom

Digital, Factor: 1 - 1, 35

• Lens


• Screen Size

80 inches - 160 inches

• Projection Lens F Number

1, 8

• Projection Lens Focal Length

2, 3 mm

• Projection Lens Focus


• Offset

7: 1

• Interfaces

USB 2.0-A (2x), USB 2.0 Type B (Service Only), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, HDMI in (2x), HDMI out, HDBaseT, Miracast

• Epson iProjection App

Ad-Hoc / Infrastructure

• Network Protocol


• Security

Kensington lock, Control panel lock, Password lock, Padlock, Wireless LAN unit lock, Wireless LAN security, Password protection

• 3D


• 2D Colour Modes

Dynamic, Natural, Cinema, Presentation, Blackboard, DICOM SIM

• Other features

21:9 aspect ratio support, 4K enhancement, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Daisy chain Multi-Projection, Digital zoom, Direct Power on/off, Document Camera Compatible, Edge Blending, Email notification, Fit to Screen, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, PC Free, Point correction, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Source function, Split-Screen-Function, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App

• Interactivity


• Video Colour Modes

Blackboard, Cinema, Dynamic, Natural, Presentation, DICOM SIM, Multi Projection

• Projector control

Via: AMX, Extron, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol


• Power consumption

290 Watt - On mode power consumption (Normal)
380 Watt (Peak), 286 Watt (Eco), 0,4 Watt (Energy saving standby)

• Heat Dissipation

1.292 BTU/hour (max)

• Supply Voltage

AC 100 V - 240 V, 50 Hz - 60 Hz

• Product dimensions

695‎ x 341 x 156 mm (Width x Depth x Height)

• Product weight

12, 5 kg

• Noise Level

Normal: 35 dB (A) - Economy: 26 dB (A)

• Supported Temperature

Storage -10° C - 60° C

• Supported Humidity

Operation 20% - 80%, Storage 10% - 90%
If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.

If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.

• Included Software

Epson Creative Projection, EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management, Epson Setting Assistant

• Options

Air filter, Ceiling mount, Connection and control box, MB22 ceiling mount, Safety wire set, Visualizer camera, WP System - ELPWP10, WP System - ELPWP20, Wall mount, Wireless LAN unit, Wireless transmitter - ELPWT01

• What's in the box?

Power cable, Quick Start Guide, Remote control incl. batteries

• Room Type / Application

4K Streaming, Boardroom, Huddle space / Portable, Large Meeting Room / Auditorium, Meeting room / Classroom, Signage / Retail, Visitor Attraction

• Positioning

Ceiling Mounted, Desktop, TV Cabinet, Wall Mounted

• Colour


• Warranty

60 months Carry in or 12.000 h


EB-810E Datasheet PDF
