Wolfvision Wireless Presentation System - CYNAPPURE

Wolfvision
WVCYNAPPUREWIRWPSYS
R 33,680.40 Ex VAT

Wireless presentation and BYOM web meetings made easy!

Compact wireless presentation system with all the functionality of Cynap Pure Mini plus additional useful features. Like all Cynap family systems, this model supports AirPlay, Miracast, and Chromecast screen sharing, ensuring best-in-class wireless screen mirroring at all times.

• BYOD Wireless screen mirroring

• BYOM web conferencing

• Live Viewer / Moderator Mode

• Integrated whiteboard feature

• Digital signage function

• Enterprise level security

No apps, no buttons, no cables, no hassle

Cynap Pure supports AirPlay, Miracast, and Chromecast screen mirroring, so no apps, buttons, dongles, or extra software are needed when sharing content on-screen from any smartphone, laptop, or tablet.

Hybrid meetings made easy!

Simply use our WolfVision vSolution App on your laptop in BYOM Mode to enable swift wireless connection to Cynap - plus connected camera, microphones, and speaker peripherals already installed in the meeting room. Users can now host web meetings using any web conferencing service directly from their own laptop.

Multi-source content shared to the main screen from any laptop, smartphone or tablet, is also shared easily with remote meeting participants during web conferences.

4K UHD output resolution

4K UHD output resolution at 60 frames per second ensures that on-screen content from any device always looks superb, and the innovative touchback feature gives you latency-free remote control of your laptop while working at the main screen.

Enterprise level security

Network security is a key consideration, and our custom-built, closed, Linux system offers 100% wireless data encryption, IEEE802.1x authentication, plus customisable security features to give you exactly the level of protection you require.

Professional integration

Cynap Pure can be set up and used immediately. Settings are easy to configure, and customisable/prepared API modules ensure professional integration, whatever your requirements. Configuration is also possible to control peripheral devices.

System

Wireless presentation system

Availability

Worldwide

Operating system

Linux

Output resolution

2160p60/30, 1080p FHD 60/30, 720p

Supported devices for wireless mirroring (up to 4K depending on device)

iOS, iPadOS, Android, Windows, macOS, Chrome OS

Supported wireless mirroring protocols

AirPlay, Miracast (Peer-to-Peer and MICE), Chromecast, vSolution Cast

vSolution MATRIX compatible



Supported Software & Apps

vSolution App, vSolution Link Pro

Media Player: Supported image file formats



Media Player: Supported document file formats



Media Player: Supported audio file formats



Media Player: Supported video file formats



Max. no. of devices simultaneously displaying material on-screen

4

Dual screen function



Dual Screen Content Management



Local streaming



Webcasting



Local video recording



Capture agent (Panopto and other compatible platforms)



Cloud services



Microsoft 365 integration



vSolution Meeting room booking tool (supports Microsoft 365 / Google Calendar)



Support for touchscreen displays

Yes

Touchback control for Windows

Yes

Access to network drives



Whiteboard and annotation

Yes

Protected / Open presentation modes

Yes

Dynamic on-screen content arrangement

Yes

Web conferencing support



Remote management software

Yes, vSolution Link Pro (Cloud & on premise)

BYOM web meetings

Yes

Customisable background image

Yes

Encrypt and save personal user settings



Integrated web browser



Video inputs



HDBaseT 1.0 Input



Video outputs

1x HDMI

HDBaseT 1.0 output



HDCP support



Audio

Via HDMI Out, USB Out

USB ports

Front: 1x USB 3.0, 1x USB 2.0

Wifi standards (wifi 5)

2.4 GHz in Access Point Mode / 2.4 and 5 GHz in Infrastructure Mode

LAN ports

Yes, 1x1GigE

Data rate

Wireless up to 867Mbps

Network protocols

TCP/IP, HTTP, HTTPS, SNTP/NTP, SSL, SSH, UDP

IP configuration

DHCP, Static (IP address, Subnet mask, Default gateway, DNS server), Proxy, Interface priority

Security authentication for LAN

IEEE 802.1x

Security encryption for WLAN

WEP, WPA2, WPA2 Enterprise or IEEE 802.1x

Room Control APIs available

Yes, customisable APIs and sample Room Control modules available

Room Control System encryption

Yes

Peripheral device control

Yes

Digital signage function & screensaver

Yes

Bluetooth device discovery (if Bonjour/mDNS is disabled)

Yes

External controlling

Multi-touch display, web interface, room control system, keyboard/mouse, optional remote control

Power consumption

24W

Operating temperature / relative humidity

0°-40°C (32°-104°F) / 40-60%

Dimensions (L x W x H)

70 x 70 x 35 mm (2.76 x 2.76 x 1.37 inch)

Weight

260g (0.57lb)

Optional accessories

Remote control

Included accessories

Power supply, VESA mount (75mm/100mm)

Limited warranty

3 years (1 year CPU and SSD) (optional warranty extension excl. CPU/SSD up to 5 years)
