Wolfvision Cynap Wireless Videobar - CYNVIDBAR

Wolfvision
WVCYNVIDBARCAMVIDCO
R 98,313.48 Ex VAT

• All-in-one hybrid meeting room AV solution:

• Where Clarity Meets Collaboration

• The Cynap Videobar is a wireless presentation, web conferencing and collaboration system for small and medium-sized meeting rooms.

• It combines award-winning Cynap wireless screen sharing technology together with a high-quality web conferencing camera, built-in speakers, and microphone, to provide a single, high-performance, all-in-one, multi-functional AV system.

• 4K AI Camera 120° FOV with auto-framing

• 2x 70W loudspeakers by Fohhn

• Beamforming Microphone Array

• WolfVision Advanced Voice-Processing Engine (WAVE)

• Cynap wireless screen sharing

• BYOM wireless web meetings

• Digital signage player

• Whiteboard & annotation

• Built-in wireless screen sharing

Cynap BYOD wireless presentation technology supports AirPlay, Miracast, and Chromecast for quick and easy connection and sharing of content, both locally, and into web conferences from any laptop, smartphone or tablet.

• BYOM web meetings: Use any conferencing service you like

Any web conferencing service can be used, and meeting hosts simply use their own laptop running our vSolution App to connect wirelessly to the videobar, and then start or join web meetings directly from their own device. It‘s really easy to use, and all in-room AV equipment is controlled using a single app.

• High-performance speaker system by Fohhn

Our superb speaker system by Fohhn ensures that remote participants are clearly heard in the meeting room, providing a sense of presence and allowing for equal participation. This is crucial in hybrid meetings where ensuring that remote voices are as prominent and clear as in-room voices helps in maintaining true collaborative equity and engagement among all participants.

• WolfVision imaging technology for crystal clear, tack sharp video

WolfVision is world-renowned for its impressive camera technology, and the Cynap Videobar is no exception - it‘s equipped with a new 4K UHD  AI camera with auto-framing,  delivering crystal clear on-screen video, for an outstanding hybrid meeting experience for everybody.

• Beamforming microphone array with WolfVision Advanced Voice-Processing Engine (WAVE)

With a pick-up range of up to 7 metres, adaptive beamforming microphones with noise suppression, automatic gain control and acoustic echo cancellation, together with the WolfVision Advanced Voice-Processing Engine (WAVE) ensure unrivalled sound pickup and reproduction.

• Unique partnership for outstanding all-in-one system

At WolfVision, we have been developing camera systems for over 30 years and wireless presentation and collaboration systems for around a decade. Our partner Fohhn also has 30 years of experience and is well-known as a premium manufacturer of loudspeakers. Together we have developed a new videobar system that is unique: whether it is used for in-room meetings or for web conferencing – the Cynap Videobar delivers a unique all-in-one solution for both applications.

• Whiteboarding & annotation tools

Add to your content material using our annotation feature - or use the built-in whiteboard to note down your ideas. Pin material such as output from a connected camera or Visualizer to the screen, or use  the mind map function for a superb collaborative experience.





Operating System

Linux

Output resolutions

2160p60/30,1080p60/30, 720p

vSolution Link Pro software for remote management & firmware updates

Yes, Cloud and on premise

Live Viewer Mode (browser-based live view of onscreen content on own device)

Yes

Supported devices for wireless screen sharing (up to 4K depending on device)

iOS, iPadOS, Android, Windows, macOS, Chrome OS

Supported mirroring protocols

AirPlay, Miracast (no HDCP support), Chromecast, vSolution Cast

Max no. of onscreen windows

4

Touchback functionality

Yes, for Windows (Miracast & vSolution Cast), macOS via vSolution App

Digital signage function and screensaver

Yes

Whiteboard and annotation

Yes

Presentation modes

Protected Mode/Open Mode

Dynamic on-screen content arrangement

Yes

BYOM (Bring Your Own Meeting) web conferencing

Yes

Customizable background image

Yes

Video inputs

1x HDMI In

Video outputs

1x HDMI Out

LAN port

Yes 1x 1GigE

Audio Outputs

Via HDMI out; 3.5mm Line Out

Audio Inputs

3.5mm Line In; Bluetooth

USB ports

USB-A 2.0 x1; USB-C 3.0 x1

Camera

8MP 4K camera. 120° FOV, Auto-framing and speaker tracking

Microphones

Beamforming Microphone Array with 4x MEMS microphones, WolfVision Advanced Voice-Processing Engine (WAVE)

Loudspeakers (by Fohhn)

2 x 70W, 2 x 4“ chassis, with coaxial high frequency diffraction waveguide and bass-reflex port

Frequency response

tbc.

SNR (Signal-to-noise ratio)

>110dB

EQ adjustment for room acoustic optimisation

Yes

Bluetooth device discovery

Yes

WiFi standards (Wifi 5)

2.4 GHz in Access Point Mode / 2.4 and 5 GHz in Infrastructure Mode

Network protocols

TCP/IP, HTTP, HTTPS, SNTP/NTP, SSL, SSH, UDP

RMS encryption

Yes

IP configuration

DHCP, Static (IP address, Subnet mask, Default gateway, DNS server), Proxy, Interface priority

Security authentication for LAN / Security encryption for wireless WLAN

IEEE 802.1X / WEP, WPA2, WPA2 Enterprise or IEEE 802.1X

External controlling

Multi-touch display, web interface, room control system, keyboard/mouse, remote control, vSolution App

Peripheral device control

Yes

Power consumption

Max 100W

Free firmware updates

Yes

Dimensions (L x W x H)

782 x 92 x 147 mm (30,79 x 3,62 x 5,79“)

Optional accessories

Remote control

Weight

tbc.

Included accessories

Power supply, wall mount

Made in

EU / Austria & Germany

Warranty

3 years limited warranty, optional warranty extension up to 5 years



CYNVIDBAR Datasheet PDF
